Compatible with Coleman KT196 Go Kart torque converter asymmetric belt.

Compatible with Coleman Powersports KT196cc 4 Wheelers 196cc 6.5HP Go Kart Buggy.

This belt is also used on many mini bikes and go-karts with the Torque-a-verter drive system.

Width: 1.91cm / 0.75 inch(approx). Length: 68.66 cm/ 27 1/32 inch(approx).

All of our parts are specially designed to exact OEM standards, manufactured and tested to help deliver optimum performance, with lifetime warranty against manufacturer defect.
Item Package Quantity:2
Specification:
100% brand new and high quality drive belt.
Color: black.
Warranty: yes.
This drive belt can be used as a Compatible with your old or worn one.
Package includes: 2 x drive belts.
Compatible with:
Compatible with Coleman KT196 Go Kart torque converter asymmetric belt.
Compatible with Coleman Powersports KT196cc 4 Wheelers 196cc 6.5HP Go Kart Buggy.
This belt is also used on many mini bikes and go-karts with the Torque-a-verter drive system.
Size:
Width: 1.91cm / 0.75 inch(approx).
Length: 68.66 cm/ 27 1/32 inch(approx).
The belt is asymmetric with a 3/4 inch wide top face, 18 degree angle on one side, 2.5 degree angle on the other side.
Instruction is not included, professional installation is highly recommended.
Please be carefully check the goods appearance, size, shape before ordering.
Features:
Designed for superior,high mileage and performance.
Made of excellent quality rubber material,it’s sturdy and durable in use.
Tested under severe environmental conditions to deliver maximum performance in any terrain or weather.
How to Select the correct belt
1. Determine the series type.
2. Measure the ??Outer Diameter?? (O.D.) of the driven pulley on the jackshaft.
3. Measure the ??Center Distance?? (C.D.), which is the exact distance between the center of the engine crankshaft and the center of the jackshaft, must be precise.
4. Use the two measurements, the driven pulley outer diameter and center distance measurement to determine the correct belt part number from the relevant chart below.
Note:
Should your machine’s center distance fall between the center distance (C.D.) settings listed here, select from the two belts the one with the larger outside circumference (O.C.) for best wear and to avoid machine ??creep?? during idling.
