Brand new premium CVT belt for 20 series Comet torque converter. Belt fit for Comet#203581/203581A Fits Comet 20 Series Torque Converters for 3 to 8hp engines. Symmetric 20 series drive belts: 3/4″ top width, 30.25″ outer circumference (30 15/64), 30 degree angle. Measured from the center of the clutch to the center of the driven pulley, the center distance is between 8-3/16″ to 8-1/4″(6″ Driven) or 7-5/16″ to 7-3/8″(7″ Driven).
How to Select the Correct Comet Belt 1.Determine the Series Type 2.Measure the “Outer Diameter” (O.D.) of the driven pulley on the jackshaft. 3.Measure the “Center Distance” (C.D.); which is the exact distance between the center of the engine crankshaft and the center of the jackshaft. Must be precise. 4.Use the two measurements; the driven pulley outer diameter and center distance measurement to determine the correct belt part number from the relevant chart below. Note: Should your machine’s center distance fall between the center distance (C.D.) settings listed here, select from the two belts the one with the larger outside circumference (O.C.) for best wear and to avoid machine “creep” during idling. Fitment: OEM Part Number: 203581, 203581A, 203581B, 203581C. This replacement go-kart belt used on yerf-dog and Hammerhead go-karts and dune buggies, etc. Center to Center Spacing for the Driver and Driven Pulley needs to be Between 8-3/16″ to 8-1/4″(6″ Driven) or 7-5/16″ to 7-3/8″(7″ Driven). Fits Comet 20 Series Torque Converters for 3 to 8hp engines.
SPECIFICATION: Material:Rubber Color:Black Size:Width: Width:3/4″ top width (19 mm), Length: 30-1/4″ (765 mm) Referenced Number:203581,203581A Package Weight: Approx. 150g Package includes: 1X Drive Belt
Spec
3/4″ top width 30 degree symmetric belt for Comet 20 Series Clutch System.Fits Comet 203581, Rotary 13047, Go Kart 884-85.
Made with high quality rubber, durable, flexible and heat resistant.This is a great replacement belt for the old or worn one.
Use with 6″ driven with 8-3/16″ to 8-1/4″ center to center distance or 7″ driven with 7-5/16″ to 7-3/8″ center to center distance.Pls check all information to ensure that the product is compatible with your unit.
Go Kart Drive Belt
Go Kart Drive Belt
CVT Drive Belt
CVT Drive Belt
OEM Part Number
203591- Q430203W 203589, 5959 203581, 203581A 669 18 30
Series
30 Series 30 Series 20 Series –
